Cam action mitre lock function allowing the user to quickly adjust angles between 0° - 50° left and 0° - 60° right•Compact and lightweight design characteristics deliver a saw with application focused capacities which is easy to transport around the jobsite
The innovative grooving stop allows the adjustment of the cutting depth for grooving and rebating applications
The large dual sliding fence gives maximum support in large material cuts at any angle or combination of angles. Includes integrated short stop for repetitive cuts
Linear horizontal rails utilise bronze guides to provide maximum precision when cutting materials up to 305 mm wide
Quick release bevel setting provides accurate and simple setting of bevel angles up to 48° left and right
XPS Shadow line cut indicator provides fast accurate alignment of the blade while illuminating the work piece for increased productivity
AIRLOCK compatible dust extraction improves cut line visibility and provides cleaner and safer jobsites
Wireless Tool Control allows automatic wireless connection to DCV586 extractor
ToolConnect tag ready (tag not supplied)
Technical Specification:
Power Source - Cordless
Battery Voltage - 54 Volt
Battery Chemistry - Li-Ion
Blade Diameter - 250mm
Blade Bore - 30mm
Blade Speed - 4300 rpm
Bevel Capacity - 49/49°
Mitre Capacity [right/left] - 60/50°
Cutting Capacity at 90°/90° (W x H) - 305 x 77mm
Cutting Capacity at 90°/45° (W x H) - 305 x 50mm
Cutting Capacity at 45°/90° (W x H) - 210 x 77mm
Max. Cutting Capacity at 45° / 45° - 210 x 50mm
Max. Depth of Cut - 150.0mm
Weight - 20.5kg
Weight (Inclu. battery) - 21.5kg
Depth - 480mm
Length - 770mm
Height - 460mm
Sound Pressure - 100dB(A)
Sound Pressure Uncertainty - 3dB(A)
Sound Power - 112dB(A)
Sound Power Uncertainty - 3dB(A)
